John Deere Alternator
Fits Aurora 45, Corsaro 70, Drago, Falcon & More (33 Amp)
Keep your John Deere running with this 33 Amp 12V replacement alternator. Designed as a direct-fit replacement for the tractor, crawler listed below, it delivers reliable charging for standard and accessory electrical loads.
This unit features an external fan (EF) and an internal regulator (IR), and is supplied with a V1 pulley already fitted.
Key Features
- ✔High Capacity: 33 Amps of charging output.
- ✔Direct Replacement: Replaces Arrowhead ABO0208.
- ✔Pulley Fitted: V1 pulley installed and ready to fit.
- ✔Robust Design: EF fan. IR regulator.
- ✔Quality Assured: New aftermarket unit, 12 month warranty.
Technical Specs
| Voltage: | 12 Volts |
| Amperage: | 33 Amps |
| Rotation: | CW (Clockwise) |
| Pulley: | V1 (Single Groove) |
| Regulator: | Internal (IR) |
| Fan Type: | External (EF) |
| SKU Reference: | 400-24134 |
Vehicle Fitment Guide
| Make | Equipment Type | Models | Years |
|---|---|---|---|
| Same | Tractor | Aurora 45, Corsaro 70, Drago, Falcon, Panther, Sirenetta | 1977–1988 |
| Same | Crawler | Fox 35, Fox 45, Fox 55 | 1986 |
| John Deere | Tractor | 1130, 1140, 1140F, 1140V, 1630, 1630OU, 1630VU, 1635, 1635EF, 1635EV, 1640, 1640F, 1830, 1840, 1840F, 2020, 2030, 2030OU, 2035, 2035EF, 2040, 2040F, 2040S, 2120, 2130, 2135, 2140, 2240, 2750, 2840, 2940, 2950, 3030, 3040, 3130, 3135, 3140, 3340, 925, 930VU, 935, 940, 940V, 945, 952 | 1970–1986 |
| John Deere | Tractors - Industrial | 2150 | 1983–1986 |
| John Deere | Tractors - Utility | 1530, 2030, 2040, 2150, 2240, 2255, 2350, 2550, 820, 830, 840, 920, 930 | 1968–1987 |
| Same | Crawlers | Condor C, Fox 35, Fox 45, Fox 55 | 1980–1986 |
| Same | Engines | 982LP, 983P, 984P | 1970–1983 |
| Same | Tractors | Aurora 45, Delfino 35, Falcon, Ranger 45, Sirenetta, Vigneron 35, Vigneron 45, Vigneron 50, Vigneron 60 | 1973–1982 |
OEM Part Number Cross Reference
| Arrowhead | ABO0208, BAL904X, IA0784, MG438 |
| Bosch | 0-120-339-512, 0-120-339-513, 0-120-339-532, 0-120-339-544, 0-120-339-545 |
| Cargo | 111649 |
| Hatz | 40099300 |
| Hyster | 3042325 |
| John Deere | AL32141, AL36100, AZ23314, AZ23575, TY6651 |
| Lester | 13194 |
| Letrika (iskra) Aftermarket IA | 0784 |
| Letrika (iskra) Description | AAG1343 |
| Letrika (iskra) OEM | 11.201.784 |
| Mahle | MG438 |
| Massey Ferguson | 3165-252-M1 |
| Volvo | 6204754 |
Frequently Asked Questions
Will this fit my John Deere Aurora 45?
Yes — the Aurora 45 appears in the fitment guide above. Check your existing part number against the cross reference table to confirm.
Is this a 33 Amp alternator?
Yes, this is a 33 Amp 12V unit with an IR regulator.
Is the pulley included?
Yes, a V1 pulley is pre-installed.
Is this new or remanufactured?
This is a brand new aftermarket unit — not a remanufactured core.
Note: Please verify your machine's serial number or existing part number to ensure compatibility.
