RELIABILITY: Engineered with high-temperature epoxy and heavy-duty rectifiers to withstand the extreme heat of long-haul trucking environments.

Key Features

• ✔ High Output: 160 Amp rating for superior charging.
• ✔ Direct Fit: Designed to OEM J180 hinge mount specs.
• ✔ Precision Clocking: 0.5 (12:30) terminal orientation.
• ✔ Brand New: 100% new components, no core charge required.

Technical Specs

Voltage:	12V
Amperage:	160 Amp
Mount Type:	J180 Hinge
Rotation:	CW (Clockwise)
Fan Type:	External Fan
Regulator:	Internal Regulator

Make	Model/Series	Year Range
Kenworth	W900 Series (All Engines)	1991 - 1999
Kenworth	T600 / T800 / T400 / T450	1991 - 1999
Engine Models	Caterpillar 3306, 3406 / Cummins L10, M11	Common Application

Is this a genuine original part?

This is a premium quality 4Drive / Aftermarket replacement part, manufactured to meet or exceed original equipment (OE) standards for fitment and performance.

How do I know if it is compatible?

We recommend checking the SKU 400-16158 and the Cross Reference list above. This unit is a standard 160A upgrade for the W900 series. If your current alternator uses a J180 hinge mount, this will fit.

What does "0.5 Clock" mean?

This refers to the positioning of the output terminals and regulator. On this model, they are oriented at approximately the 12:30 (0.5) position when viewed from the rear, which is the standard configuration for Kenworth W900 applications.
