Alternator for Marine Applications - Delco 10SI Series 94A 2-Wire
Alternator for Marine Applications - Delco 10SI Series 94A 2-Wire
SKU:400-20015
Free shipping over £150. Terms apply
Couldn't load pickup availability
Alternator for Marine Applications - Delco 10SI Series 94A 2-Wire
Marine applications - Delco 10SI series, 2-wire hook-up, 94A
This alternator is built for marine engine applications as a Delco 10SI series conversion unit, supplied to replace the original Motorola-pattern alternator fitted to many marine engines. This is the 2-wire hook-up version, rated at 94 amps, suited to engines wired for a separate excitation feed.
It is manufactured to OEM specifications for output and mounting, with an internal regulator (IR) and external fan (EF) cooling, plus a 1-inch bottom mounting foot matching the original bracket and a 1-V pulley. The higher 94 amp rating gives extra charging headroom over the standard 63 amp version for boats running more onboard electronics.
Key Features
- 12-volt marine alternator
- 94 amp output (Delco 10SI series)
- 2-wire hook-up
- 1-inch bottom mounting foot
- Internal regulator (IR), external fan (EF)
Technical Specs
| Specification | Detail |
|---|---|
| Voltage | 12V |
| Amperage | 94A |
| Pulley Type | 1-V |
| Fan Type | External Fan (EF) |
| Regulator | Internal Regulator (IR) |
Vehicle Fitment Guide
Universal fitment - this part is not model specific. Check the specifications above against the unit you are replacing.
OEM Part Number Cross Reference
Aftermarket replacement. OEM part numbers are listed for reference only.
No OEM cross reference is published for this part.
Frequently Asked Questions
Will this fit my marine engine without modification?
This is a Delco 10SI series conversion unit designed to replace Motorola-pattern alternators - check your original unit's pulley and mounting foot match before ordering, as replaced Motorola units with a 15mm ID pulley will not transfer across.
What is included?
One new 12-volt Delco 10SI series marine alternator, ready to fit.
How do I know my old alternator has failed?
Signs include a charge warning light, a battery that discharges even with the engine running, dimming instruments or lights, or a grinding/whining noise from the unit.
What wiring configuration does this unit use?
A 2-wire hook-up. A 1-wire hook-up version of this unit (63 amp) is also available separately.
