Alternator for Volvo Penta 4.3L, 5.0L & 5.7L Engines 2000-2007
Alternator for Volvo Penta 4.3L, 5.0L & 5.7L Engines 2000-2007
SKU:400-40116
Free shipping over £150. Terms apply
Couldn't load pickup availability
Alternator for Volvo Penta 4.3L, 5.0L & 5.7L Engines
Fits Volvo Penta 4.3L, 5.0L & 5.7L GM-based Marine Engines, 2000 onwards
This alternator is built to OEM specifications as a direct fit-and-function replacement for Volvo Penta 4.3L, 5.0L and 5.7L GM-based marine engines. It mounts onto the original bracket using the factory single-groove pulley.
It is a 12-volt, 65-amp clockwise-rotation unit with an internal regulator (IR) at the 2 o'clock clock position and an internal fan (IF), fitted with a 1-V pulley (73mm OD), an M8 x 1.25 B+ post, S and L spade terminals and the factory L-D (light-dummy) plug wiring. It is negative earth and uses one 5/16-18 threaded mounting hole and one unthreaded hole. Fitting follows the same steps as removing and refitting the original unit, using a standard socket set - no special tools or wiring changes are needed.
Key Features
- 12-volt, 65-amp output
- 1-V pulley, 73mm OD
- Clockwise (CW) rotation
- Internal regulator (IR), internal fan (IF)
- M8 x 1.25 B+ post, S and L spade terminals, L-D plug wiring
- Direct OEM fit for Volvo Penta 4.3L, 5.0L & 5.7L engines
Technical Specs
| Specification | Detail |
|---|---|
| Voltage | 12V |
| Amperage | 65A |
| Rotation | Clockwise (CW) |
| Pulley Type | 1-V, 73mm OD |
| B+ Post | M8 x 1.25 |
| Additional Terminals | S (spade), L (spade) |
| Plug Type | L-D (Light-Dummy) |
| Fan Type | Internal (IF) |
| Regulator | Internal (IR), 2 o'clock clock position |
| Mounting | One 5/16-18 threaded hole, one unthreaded hole |
| Polarity | Negative earth |
| Manufacturer Reference | Lester 12672 / Arrowhead AVA0119 |
Vehicle Fitment Guide
Years shown are the overall coverage span for this part. Please confirm against the OEM part number on your original unit before ordering.
| Make & Model | Years |
|---|---|
| Volvo Penta 4.3L Marine Engine | 2000-2007 |
| Volvo Penta 5.0L Marine Engine | 2000 onwards |
| Volvo Penta 5.7L GM Marine Engine | 2000 onwards |
OEM Part Number Cross Reference
Aftermarket replacement. OEM part numbers are listed for reference only.
| Part Number | Manufacturer / Brand |
|---|---|
| 3862612 | Volvo Penta |
| 2656299, 425299, A0002655299 | Valeo |
| LRA03021 | Lucas Electric |
| AVA0119 | Arrowhead |
| 4-6848 | EMP |
| 12672 | Lester |
Frequently Asked Questions
Will this alternator fit without modification?
Yes, it uses the same mounting, pulley and plug configuration as the original Volvo Penta unit.
What's included?
One new alternator unit with the 1-V pulley fitted, ready to install.
How do I confirm this is the right unit for my engine?
Check the Volvo Penta number 3862612 or the Valeo numbers 2656299, 425299 and A0002655299 against the tag on your original alternator, or match the Lester 12672 reference.
How do I know my old alternator has failed?
Look for a battery that won't hold charge, a charge warning light, or dimming lights at idle.
What pulley does this unit use?
A single V-groove (1-V) pulley with a 73mm outside diameter.
