Starter Motor Brush 414-54015 for Honda, Kawasaki, Yamaha Motorcycles
Starter Motor Brush 414-54015 for Honda, Kawasaki, Yamaha Motorcycles
SKU:414-54015
Free shipping over £150. Terms apply
Couldn't load pickup availability
Starter Motor Brush 414-54015 for Honda, Kawasaki, Yamaha Motorcycles
New aftermarket replacement part
Starter Motor Brush 414-54015 for Honda, Kawasaki, Yamaha Motorcycles - a new aftermarket brush set, supplied ready to fit.
Brushes are the wear item inside every starter and alternator. Replacing them at the first sign of slow cranking or intermittent charging saves the whole unit.
Key Features
- 100% new aftermarket unit - not a remanufactured core
- Direct-fit replacement, no modification required on listed applications
- Built to meet or exceed the original equipment specification
- Dispatched from the UK with technical fitment support
Technical Specs
| Specification | Detail |
|---|---|
| SKU / Part Code | 414-54015 |
| Component | Brush Set |
| Condition | New aftermarket |
| Warranty | 12 months |
Vehicle Fitment Guide
| Model | Years |
|---|---|
| Kawasaki ATV KLT 200 (1981-1984), KLT 250 | 1982-1983 |
| Honda CB 175 | 1970-1974 |
| CB 200 | 1970-1976 |
| CB 350 | 1967-1974 |
| CB 360 | 1976-1977 |
| CJ 360T | 1976-1977 |
| CL 175 | 1973-1977 |
| CL 350 | 1972-1977 |
| CL 360 | 1975-1977 |
| SL 350 | 1972-1977 |
| Kawasaki KZ 200 (1977-1979), KZ 250 CSR (1980-1981), KZ 400 | 1976-1979 |
| Yamaha XS 360 (1976-1977), XS 400 | 1977-1980 |
Frequently Asked Questions
How do I know when brushes need replacing?
Worn brushes cause slow cranking, intermittent operation that improves after tapping the housing, and visible arcing. Compare the length against the service limit in your manual.
Are the springs included?
Check the images and specification table - sets are supplied as the original was configured.
Do I need to skim the commutator?
If the commutator is grooved or has raised insulation between segments, have it skimmed and undercut before fitting new brushes, or they will wear quickly.
Is this a direct fit?
Yes - it matches the original brush geometry on the units listed in the cross-reference table.
