Lucas C40T Tach Drive Dynamo Generator 12V 22A Massey Ferguson 135 Fordson Dexta
Lucas C40T Tach Drive Dynamo Generator 12V 22A Massey Ferguson 135 Fordson Dexta
SKU:142-30001-4
Free shipping over £150. Terms apply
Couldn't load pickup availability
Lucas C40T Tach Drive Generator
Premium 12V Replacement Dynamo
This high-performance replacement Lucas C40T Dynamo is engineered to restore charging efficiency and tachometer functionality to your classic tractor or vehicle. Unlike standard C40 units, the C40T features a specialized rear-mounted drive for mechanical rev counters (tachometers), making it essential for Perkins-powered Massey Ferguson models and Fordson Dexta applications.
Key Features
- ✔ Integrated mechanical tachometer drive
- ✔ Direct fit for 12V 2-brush systems
- ✔ High-grade copper windings
- ✔ Weather-proofed connections
Technical Specs
| Voltage | 12V |
| Amperage | 22A |
| Rotation | Clockwise (CW) |
| Shaft Diameter | 15mm |
| Flange Distance | 144mm |
Compatibility / Fitment Guide
| Make/System | Model/Application | Notes |
|---|---|---|
| Massey Ferguson | 35, 35X, 135, 148, 165 | With Perkins Diesel Engines |
| Fordson | Dexta, Super Dexta | Mechanical Tacho Models |
| Case IH | B275, B414, 434 | C40T Variant |
| Classic Sports | Various MG, Triumph, Austin Healey | Check Rear Drive Type |
OEM Cross Reference
| Lucas | 22756, 22704, 22715, 22748, 22758, 54021200, LRD101 |
| Massey Ferguson | 1818204M91, 1902038M91, 1827461M92, 897104M92 |
| Perkins | 2871181, 2871182 |
Questions & Answers
Is this a genuine original part?
This is a premium quality aftermarket replacement part, manufactured to meet or exceed original equipment (OE) standards for fitment and performance.
How do I know if it is compatible?
We recommend checking the SKU/MPN and Cross Reference list provided above. If your original part number matches any of these, it is a guaranteed fit.
What is the difference between a standard C40 and a C40T?
The 'T' suffix indicates that this unit is equipped with a mechanical gear on the rear plate, specifically designed to drive a mechanical tachometer cable. A standard C40 does not have this drive.
Note: Please verify your original part number against the references above before purchasing. This unit requires polarising upon installation to match your vehicle's ground system.
Visit 4drive.co.uk for more technical support.
