DIRECT FIT / KEY SELLING POINT: Experience unparalleled convenience with four fully independent charging channels, allowing simultaneous and tailored maintenance for up to four batteries with spark-proof, short-circuit, and reverse polarity protection.

Key Features

• ✔ Four Independent Channels: Simultaneously charge and maintain up to four 12V batteries.
• ✔ 9-Stage Charging Algorithm: Ensures comprehensive recovery, charging, and maintenance for all battery types.
• ✔ Automatic & Fully Monitored: Plug-and-forget operation with automatic voltage detection and charge cycle management.
• ✔ Advanced Safety Protection: Built-in spark-proof, reverse polarity, and short-circuit protection for safe use.
• ✔ Sulfation Prevention: Pulse and recondition phases actively work to desulfate plates and extend battery life.
• ✔ Temperature Compensated: Optimized charging performance in varying environmental conditions.

Technical Specs

Charger Type:	Quad Bank Charger & Maintainer
Voltage:	12V DC
Input:	Auto-switching 100-240V AC - 50/60Hz
Output Current:	2A per channel (max)
Max Voltage:	14.9V
Battery Capacity:	Charging 4-100Ah – Maintenance all sizes
Compatible Battery Types:	12V AGM, Gel, Standard Lead Acid
Safety Features:	Overcharge, Reverse Polarity, Short Circuit, Spark Proof
Safety Timer:	72 Hours

Category	Common Applications	Battery Types
Motorcycles	Street bikes, Cruisers, Dirt bikes, Scooters	12V AGM, Gel, Lead Acid
ATVs / UTVs	Quads, Side-by-Sides, Utility Vehicles	12V AGM, Gel, Lead Acid
Marine	Jet Skis, Small Boats, Personal Watercraft	12V AGM, Gel, Lead Acid
Other Powersports	Snowmobiles, Lawn Mowers, Golf Carts	12V AGM, Gel, Lead Acid

What types of batteries can the Motobatt Quad Bank Charger charge?

This charger is designed for 12V Standard Flooded, AGM (Absorbent Glass Mat), and Gel Lead Acid batteries. It is not compatible with Lithium batteries.

Can I charge multiple batteries at once?

Yes, the Motobatt Quad Bank charger features four independent charging channels, allowing you to safely and efficiently charge and maintain up to four 12V batteries simultaneously.

What safety features does this charger include?

It comes equipped with comprehensive safety features including spark-proof connections, reverse polarity protection, short-circuit protection, overcharge protection, and a 72-hour safety timer to ensure safe and reliable operation.

How does the 9-stage charging process work?

The 9-stage process includes qualification, rescue, soft start, pulse, recondition, bulk charge, absorption, check, and maintenance phases. This ensures optimal charging, recovery of deeply discharged batteries, sulfation prevention, and long-term battery health.
