Pick-Up Coil 150 Ohms - Part RM00149
Arctic Cat, Can-Am, Honda Fourtrax, Kawasaki, Polaris Outlaw, Phoenix and Sportsman 50-200cc, 1993-2024
This is a brand new pick-up coil, also known as a pulsar coil or trigger coil, supplied so that you can repair your existing stator rather than replace the complete assembly. It is the small sensor that sits alongside the flywheel and tells the ignition system exactly where the crankshaft is, so the CDI can fire the spark at the right moment. On the small-capacity ATVs and utility quads covered here the pick-up coil is one of the most common failure points, and it is often no longer available separately from the original manufacturer.
The coil is wound to a nominal 150 ohms and carries a single blue wire with a 670 mm lead, mounted on a bracket with 35 mm hole centres. Every unit is tested before it leaves us. If you are in any doubt about fitment, compare the bracket spacing, the wire length and the resistance figure below against the coil currently on your machine, and check the OEM number stamped on your original part against the cross reference table further down this page.
Key Features
- Brand new pick-up / pulsar coil, not a reconditioned part
- Lets you repair the stator instead of buying a complete new one
- Nominal 150 ohm winding, blue to ground, within plus or minus 20 per cent
- Two wires with a generous 670 mm lead length
- Bracket drilled at 35 mm centre to centre
- Frequently discontinued as a separate item by the original manufacturer
- Every coil is tested before dispatch
- Dispatched from the UK with a 12-month warranty
Technical Specs
| Specification | Detail |
|---|---|
| Part number | RM00149 |
| Bracket centre to centre | 35 mm |
| Wire length | 670 mm |
| Number of wires | 2 |
| Wire colour | Blue |
| Resistance | Blue to ground = 150 ohms +/- 20% |
| Engine size range | 50-200cc |
| Condition | Brand new, tested before shipping |
Vehicle Fitment Guide
Years shown are the overall coverage span for this part. Please confirm against the OEM part number on your original unit before ordering.
| Make & Model | Years |
|---|---|
| Arctic Cat 50-200cc models | 1993-2024 |
| Can-Am 50-200cc models | 1993-2024 |
| Honda Fourtrax | 1993-2024 |
| Kawasaki 50-200cc models | 1993-2024 |
| Polaris Outlaw | 1993-2024 |
| Polaris Phoenix | 1993-2024 |
| Polaris Sportsman | 1993-2024 |
OEM Part Number Cross Reference
Aftermarket replacement. OEM part numbers are listed for reference only.
| Part Number | Manufacturer / Brand |
|---|---|
| 21003-Y001 | OEM cross reference |
| 21003-Y003 | OEM cross reference |
| 31120-HF7-003 | OEM cross reference |
| 3303-416 | OEM cross reference |
| 3305-254 | OEM cross reference |
| 0452449 | OEM cross reference |
| 0453559 | OEM cross reference |
| 0454228 | OEM cross reference |
| 0454483 | OEM cross reference |
| 0454944 | OEM cross reference |
| 0454947 | OEM cross reference |
| 0454949 | OEM cross reference |
| V31100CJF010 | OEM cross reference |
| BD3-H1410-00-00 | OEM cross reference |
Frequently Asked Questions
Does this coil need any modification to fit?
No. It is built to the original dimensions, with 35 mm bracket hole centres and a 670 mm lead, so it mounts and routes the same way as the coil you are removing. Check those two figures against your old part before you order.
What is included?
You receive the pick-up coil itself with its bracket and its two-wire lead. No further items are listed for this part, so reuse the original fixings and any connector housing from your old coil where needed.
How do I know my old pick-up coil has failed?
The usual signs are no spark at all, an intermittent spark that comes and goes with engine temperature, hard starting, or a machine that cuts out and then restarts once it has cooled. Measure the coil with a multimeter: blue to ground should read close to 150 ohms. An open circuit reading, a short to ground, or a figure well outside the plus or minus 20 per cent tolerance all point to a failed coil.
Do I have to replace the whole stator as well?
Not necessarily. This part exists precisely so that a stator with a good charging winding but a dead trigger coil can be repaired. If the charging coils on your stator still test correctly, fitting this pick-up coil is usually all that is required.
