Voltage Regulator Rectifier for Can-Am, Arctic Cat & Kymco
Can-Am DS, Arctic Cat Utility and Kymco Mongoose & MXU - 2003-2024
This is a brand new aftermarket voltage regulator rectifier, supplied as a direct replacement to your original unit on Can-Am DS, Arctic Cat Utility and Kymco Mongoose and MXU machines. It is plug-and-play and a direct fit, with no assembly required, so it bolts to the original mounting and connects to the existing harness. Part number RM30903.
The manufacturer specifies a higher grade of electrical components than the original equipment, and states that the quality exceeds the OEM part. Every unit is tested before it is shipped. The regulator holds a minimum charging voltage of 14.5 V +/- 0.5 V, handles a maximum charging current of 50 A or 500 W, and keeps open circuit voltage below 15 V, with an operating range of -20 degrees C to 85 degrees C. The body measures 78 mm long by 79 mm wide by 31 mm high, the fixing holes are 63 mm apart centre to centre, and there are six wires in two lengths, 147 mm and 160 mm, terminating in two plugs across six pins.
Key Features
- Brand new aftermarket voltage regulator rectifier
- Direct replacement to your original unit
- Plug-and-play, direct fit, no assembly required
- Higher grade of electrical components
- Quality exceeds the OEM equipment
- Maximum charging current 50 A / 500 W
- Two plugs, six pins, six wires
- All products shipped are tested
- Part number RM30903
Technical Specs
| Specification | Detail |
|---|---|
| Width | 79 mm |
| Length | 78 mm |
| Height | 31 mm |
| Wire lengths | 147 mm and 160 mm |
| Fixing holes, centre to centre | 63 mm |
| Number of plugs | 2 |
| Number of pins | 6 |
| Number of wires | 6 |
| Minimum charging voltage | 14.5 V +/- 0.5 V |
| Maximum charging current | 50 A / 500 W |
| Open circuit voltage | Under 15 V |
| Operating temperature | -20 degrees C to 85 degrees C |
| Part number | RM30903 |
Vehicle Fitment Guide
Years shown are the overall coverage span for this part. Please confirm against the OEM part number on your original unit before ordering.
| Make & Model | Years |
|---|---|
| Can-Am DS | 2003-2024 |
| Arctic Cat Utility | 2003-2024 |
| Kymco Mongoose | 2003-2024 |
| Kymco MXU | 2003-2024 |
OEM Part Number Cross Reference
Aftermarket replacement. OEM part numbers are listed for reference only.
| Part Number | Manufacturer / Brand |
|---|---|
| 3303-836 | Arctic Cat |
| 31600-LBA7-900 | Kymco |
| S31600RCA000 | Can-Am |
| S31600RCA010 | Can-Am |
Frequently Asked Questions
Will this fit without modification?
Yes. The manufacturer describes it as plug-and-play and a direct fit with no assembly required. The two plugs match the original connectors and the fixing holes sit 63 mm apart centre to centre. This regulator covers three different makes, so check the plug layout and confirm the OEM number on your existing unit against the cross reference table before ordering.
What is included?
You receive one brand new aftermarket voltage regulator rectifier, part number RM30903, with its six wires and two plugs already fitted. Wire lengths are 147 mm and 160 mm.
How do I know my old regulator has failed?
The common symptoms are a battery that will not hold charge and a charging voltage outside the normal band measured at the battery terminals with the engine running. This unit holds 14.5 V +/- 0.5 V with an open circuit voltage below 15 V, so a reading well outside that range suggests the regulator rather than the stator.
Is each unit tested?
Yes. The manufacturer states that all products shipped are tested, and that the unit uses a higher grade of electrical components so that its quality exceeds the OEM equipment. It is rated for operation between -20 degrees C and 85 degrees C.
