Premium Starter Motor for Kohler 12.5-15HP
Direct Replacement for Cub Cadet & Toro Garden Equipment (1209809, 12-098-05)
Restore reliable starts to your garden and lawn equipment with our brand-new, high-performance starter motor. Engineered to meet or exceed OEM specifications, this 12V, 13-tooth PMDD starter is the perfect direct replacement for a range of Kohler 12.5HP to 15HP engines found in popular Cub Cadet and Toro models.
Say goodbye to frustrating delays and get back to work faster. This aftermarket starter is built with premium components for superior durability and efficiency, ensuring consistent, no-hesitation engine starts every time you turn the key. It's a cost-effective solution without compromising on quality or performance.
Key Features
- ✔ OEM-Grade Quality: Manufactured with new, premium components to meet or exceed original equipment standards.
- ✔ Efficient Starting Power: High-quality magnets and field coils deliver maximum torque for fast, reliable engine ignition.
- ✔ Enhanced Durability: Sealed housings and bearings protect internal workings from debris and moisture, extending service life.
- ✔ Precision Engineered: Undergoes rigorous testing to ensure optimal performance, durability, and a perfect fit.
- ✔ Brand New Unit: Never refurbished or re-manufactured, ensuring fresh performance right out of the box.
Technical Specs
| Voltage: | 12 Volts |
| Rotation: | Counter-Clockwise (CCW) |
| Teeth: | 13-Tooth Pinion |
| Starter Type: | PMDD (Permanent Magnet Gear Reduction) |
Vehicle Fitment Guide
| Make | Model | Year Range |
|---|---|---|
| Cub Cadet | 1315 | 1989-1991 (Kohler 12.5HP) |
| Cub Cadet | 1320 | 1989-1991 (Kohler 12.5HP) |
| Cub Cadet | 1325 | 1992-1993 (Kohler 12.5HP) |
| Cub Cadet | 1330, 1340, 1405 | Various Years (Kohler 12.5HP) |
| Toro | GT Classic Garden Tractor | 2005-2007 |
| Toro | 315-8 Garden Tractor | 2002-2004 |
| Toro | 314-8 Garden Tractor | 1999-2001 |
| Toro | 264-H, 264-6 Yard Tractor | 1994-1996 |
| Kohler | CH11, CH12.5, CH13, CH14, CH15, CH410-CH450, CV15 Engines | Various (12.5HP-15HP) |
OEM Part Number Cross Reference
| Kohler | 12-098-05, 12-098-06, 12-098-09, 12-098-12, 12-098-19, 12-098-19S, 12-098-21, 12-098-21S |
| Johnson Electric | 6734640 |
| Original Ref. Numbers | 5239740, 5278440, 5667040 |
| Other Crosses | 239740-M030SM, 5278440-M030SM, SAB0038, 41021042, 41021083, 5771N, 5771 |
Frequently Asked Questions
What engine sizes is this starter compatible with?
This starter is designed for Kohler engines ranging from 12.5 horsepower to 15 horsepower.
Is this a new or re-manufactured starter?
This is a brand new, aftermarket starter motor, not a re-manufactured or used unit, ensuring maximum reliability.
How do I know if this starter will fit my Cub Cadet or Toro equipment?
Please refer to the "Vehicle Fitment Guide" and "OEM Part Number Cross Reference" tables above. Match your equipment's make, model, year, and existing part number to ensure compatibility.
Note: Please verify your vehicle model and year before purchasing.
Fast shipping available across the UK and Europe.
