Starter Motor for Mercury Mariner Outboard 30-60HP 1994-2009
Starter Motor for Mercury Mariner Outboard 30-60HP 1994-2009
SKU:410-21022
Free shipping over £150. Terms apply
Couldn't load pickup availability
Starter Motor for Mercury Mariner Outboard 30-60HP 1994-2009
Mercury and Mariner 30, 40, 50 and 60HP outboards - 12V, counter-clockwise rotation, 10-tooth
A starter motor is the component that cranks the engine over to begin combustion. If it fails to engage, spins without turning the engine, or does not respond at all when the key is turned or the start button is pressed, the engine will not start. This starter motor is built for Mercury Marine and Mariner outboard engines from 30HP to 60HP built between 1994 and 2009, engineered as a direct replacement that matches the original unit's fit, mounting and function.
It is a 12V permanent magnet direct drive (PMDD) unit with counter-clockwise (CCW) rotation and a 10-tooth drive pinion, with a motor housing length of 4.033in matching the original Mercury specification. It also covers the 40EO Jet 30 and 60EO Jet 45 jet-drive variants.
Key Features
- Direct fit for Mercury Marine and Mariner 30-60HP outboard engines
- Covers model years 1994 to 2009 across the range
- 12V starter motor, counter-clockwise (CCW) rotation
- 10-tooth drive pinion, PMDD design
- Motor housing length 4.033in
- 12-month warranty as standard
Technical Specs
| Specification | Detail |
|---|---|
| Voltage | 12V |
| Rotation | Counter-Clockwise (CCW) |
| Teeth | 10 |
| Starter Type | PMDD (permanent magnet direct drive) |
| Motor Housing Length | 4.033in |
Vehicle Fitment Guide
Years shown are the overall coverage span for this part. Please confirm against the OEM part number on your original unit before ordering.
| Make & Model | Years |
|---|---|
| Mercury / Mariner 30HP - 30EHO, 30ELHO, 30ELO, 30ELPTO, 30EO | 1994-2002 |
| Mercury / Mariner 40HP - 40ELHPTO, 40ELO, 40ELPTO, 40EO, 40EO Jet 30 | 1997-2005 |
| Mercury / Mariner 50HP - 50ELHPTO, 50ELO, 50ELPTO, 50EO | 1998-2009 |
| Mercury / Mariner 60HP - 60ELHPTO, 60ELO, 60ELPTO, 60EO, 60EO Jet 45 | 1998-2005 |
OEM Part Number Cross Reference
Aftermarket replacement. OEM part numbers are listed for reference only.
| Part Number | Manufacturer / Brand |
|---|---|
| 50-822462, 50-822462-1, 50-822462T1, 50-893890T, 822462T1, 893890T | Mercury Marine |
| SAB0031 | Arrowhead |
| MOT3012 | WAI |
| 5396 | ARCO Marine |
| 5726 | Lester |
| MS-6020, 206-03105, 49-0031, 9-15016 | OEM / Interchange |
Frequently Asked Questions
Will this fit without modification?
Yes, this starter motor is built to match the original Mercury outboard unit's housing length, rotation and drive pinion, so it installs as a direct swap.
What's included?
One new 12V starter motor, ready to fit.
How do I know my old starter has failed?
Common signs are a single click with no crank, a slow or straining crank, or no response at all when the key is turned or the start button pressed.
Does it fit the jet-drive versions?
Yes - the 40EO Jet 30 and 60EO Jet 45 jet-drive models share this starter. Check the Mercury part number stamped on your original unit against the cross reference above.
How do I confirm this suits my outboard's horsepower?
This starter covers the 30, 40, 50 and 60HP Mercury and Mariner range - check your outboard's horsepower rating, model year and the 4.033in motor housing length against your original unit before ordering.
