12V 200A Continuous Duty Solenoid
Universal 6-Terminal Replacement for Automotive, Marine & Industrial Applications
Ensure reliable power control in your vehicle or equipment with our high-quality 12V 200 Amp Continuous Duty Solenoid. This robust 6-terminal solenoid is engineered to provide consistent performance, making it an ideal choice for a wide array of applications, from automotive and marine starters to industrial power systems. Its heavy-duty construction is built to withstand demanding conditions, offering the durability you need for long-term operation.
Designed as a direct replacement, this aftermarket solenoid matches OEM specifications, ensuring a seamless fit and optimal functionality right out of the box. Whether you're replacing a faulty starter solenoid or upgrading an existing power control unit, this 12V, 200A unit delivers the precise switching capability required for critical electrical circuits. Trust in a product that combines professional-grade quality with exceptional value.
Key Features
- ✔ Continuous Duty: Rated for sustained operation in demanding applications.
- ✔ High Amperage: 200 Amp continuous, 600 Amp open surge capacity.
- ✔ 6-Terminal Design: Provides versatile wiring options for various setups.
- ✔ SPDT Contact Action: Single Pole Double Throw for flexible switching configurations.
- ✔ Isolated Coil: Enhances circuit protection and prevents common ground issues.
- ✔ Robust Construction: Features a durable metal case and silver contacts for longevity.
Technical Specs
| Voltage: | 12V |
| Continuous Amps (NO/NC): | 200A / 50A |
| Surge Amps (NO/NC): | 600A / 200A |
| Number of Terminals: | 6 (4x 5/16-24, 2x #10-32) |
| Duty Cycle: | Continuous |
| Mounting: | Flat 180 (F180) |
| Case Material: | Metal |
| Contact Material: | Silver |
| Coil Type: | Isolated |
| Coil Resistance: | 13.2 Ohms (at 25°C) |
Vehicle & Equipment Fitment Guide
| Application Type | Common Uses | Voltage |
|---|---|---|
| Universal | Automotive, Marine, Agricultural, Industrial | 12V DC |
| Starter Systems | Heavy Equipment, Golf Carts, Utility Vehicles | 12V DC |
| Power Relays | Auxiliary Power, Winches, Lights, General Purpose Switching | 12V DC |
OEM Part Number Cross Reference
| White-Rodgers | 124-305111, 124-305111-3, 124-910, 124-910-111, 124-910S1 |
| Arrowhead | 124-910 |
| United Technologies | 5121440, 512440, SO51214 |
| Prestolite | 15-323, SBD4201A |
| Other OEMS | 6C023 |
Frequently Asked Questions
What is a starter solenoid and how does it work?
A solenoid is an electromagnetic switch that completes the starter circuit. It engages the drive gear into the flywheel and energizes the field coils and armature to turn over the engine, initiating the starting process.
Where is the starter solenoid typically located?
Most starter solenoids are mounted directly on the starter motor itself. In some applications, they can also be found on the fender well or firewall.
What are the common signs of a failing starter solenoid?
Signs of a failing starter solenoid include the engine turning over slowly even with a fully charged battery, or the starter motor turning but not engaging the drive into the flywheel (without any clicking sounds).
Note: Please verify your equipment's specific requirements and cross-reference part numbers before purchasing.
