Starter Motor for Volvo Penta AQ Marine & Volvo 240/740/940 - 12V CW
Starter Motor for Volvo Penta AQ Marine & Volvo 240/740/940 - 12V CW
SKU:410-24048
Free shipping over £150. Terms apply
Couldn't load pickup availability
Starter Motor for Volvo Penta AQ Marine & Volvo 240/740/940 - 12V CW
Bosch-type 12V, CW, 9-tooth starter for Volvo Penta 4 & 6-cylinder marine and Volvo road engines
This starter motor is a direct-fit replacement for Volvo Penta 4 and 6-cylinder marine engines and for the Volvo road engines that share the same Bosch starter, built to the same mounting, output and mechanical specification as the original equipment unit so it bolts straight into place. Coverage spans the Volvo Penta 2001, 2002, 2002T, 2003T and 251A stern drive units and the long-running AQ100 to AQ130 petrol range, as well as Volvo 120, 140, 160, 240, 740, 760, 780, 940 and 1800 series cars.
It is a Bosch-type unit running on 12 volts, turning clockwise (CW) with a 9-tooth drive gear, and both mounting holes are threaded to match the original fitment. Hitachi, Iskra and Valeo permanent-magnet equivalents were also fitted across the production run, and cross reference numbers for those alternatives are listed below to help confirm compatibility.
Key Features
- Direct OEM fit and function for Volvo Penta 4 & 6-cylinder engines
- 12-volt, 1.1kW Bosch-type motor
- Clockwise (CW) rotation, 9-tooth drive gear
- Both mounting holes threaded to match the original unit
- 12-month warranty as standard
Technical Specs
| Specification | Detail |
|---|---|
| Voltage | 12V |
| Output | 1.1kW |
| Rotation | CW |
| Drive Teeth | 9 |
| Starter Type | Direct drive (DD) |
| Mounting | Both mounting holes threaded |
Vehicle Fitment Guide
Years shown are the overall coverage span for this part. Please confirm against the OEM part number on your original unit before ordering.
| Make & Model | Years |
|---|---|
| Volvo Penta 2001, 2002, 2002T, 2003T & 2003R stern drive | 1983-1993 |
| Volvo Penta 251A DOHC | 1989-1992 |
| Volvo Penta AQ100 to AQ130 marine range | 1961-1985 |
| Volvo 120, 140, 160 & 1800 series (1.8L-3.0L) | 1962-1975 |
| Volvo 242, 244 & 245 | 1975-1993 |
| Volvo 740, 760, 780 & 940 | 1985-1995 |
OEM Part Number Cross Reference
Aftermarket replacement. OEM part numbers are listed for reference only.
| Part Number | Manufacturer / Brand |
|---|---|
| 1306503, 1346707, 1357199, 1357373, 204284, 238620, 240360, 241615, 463854, 493856, 5001599, 5001613, 5003564, 5003617, 5240360, 5838060, 834976, 934976 | Volvo / Volvo Penta |
| 0-001-108-030, 0-001-108-088, 0-001-305-016, 0-001-311-001, 0-001-311-027, 0-001-311-103, 0-001-311-104, 0-001-311-127, 0-001-311-146, 0-001-311-147 | Bosch |
| S114-232, S114-232A | Hitachi |
| BSR37X, BSR437X, IS0777, MS266 | Arrowhead |
| 16353, 16360, 16954, 16985, 17135 | Lester |
| 17135N, 2-1285-BO, 2-1288-BO, 2-1288-HI, 2-1290-BO | WAI |
| 410-24048 | J&N Electrical Products |
| 475693 | Hitachi (equivalent) |
| 483889 | Iskra (equivalent) |
| 477596 | Bosch PMGR (replacement) |
| 476709 | Valeo PMGR (replacement) |
Frequently Asked Questions
Will this starter fit my engine without modification?
Yes. It is a direct bolt-in replacement for the Volvo Penta and Volvo engines listed above, with both mounting holes threaded to match the original unit.
Does it suit both marine and road applications?
Yes. The same Bosch starter was fitted to Volvo Penta 4 and 6-cylinder marine engines and to the Volvo car engines they were derived from, which is why both are listed in the fitment guide above.
What's included?
The starter motor unit only, complete with its drive gear ready to fit.
How can I tell my old starter has failed?
Common signs include a clicking noise when you turn the key, the engine failing to crank, the starter freewheeling without turning the engine, or a burning smell from the motor.
