RELIABILITY: Built to meet or exceed OEM specifications for high-heat durability and extreme operating environments.

Key Features

• ✔ Direct Fit: Matches OEM dimensions for easy installation.
• ✔ Durable Material: High-grade non-asbestos gasket paper.
• ✔ Heat Resistant: Designed for high-temperature engine performance.
• ✔ Leak Prevention: Ensures a perfect seal for the alternator/magneto cover.

Technical Specs

Material	Premium Gasket Paper
Placement	Engine Left Side (Stator)
Thickness	~0.8mm
Part Type	Crankcase Cover Gasket 1

Make / Model	Years	Application Notes
Yamaha Grizzly 700 (YFM700)	2007 - 2018	Includes EPS and Special Editions
Yamaha Grizzly 550 (YFM550)	2009 - 2015	All 550 models
Yamaha Viking 700 / VI	2014 - 2018	All UTV variants
Yamaha Rhino 700 (YXR700)	2008 - 2013	FI Models
Yamaha Kodiak 700 (YFM700)	2016 - 2018	Direct engine fitment

Is this a genuine original part?

This is a premium quality 4Drive aftermarket replacement part, manufactured to meet original equipment (OE) standards for fitment and high-temperature performance.

How do I know if it is compatible?

Please check your original part number against the reference 3B4-15451-00-00. This gasket fits the left side crankcase cover (stator cover) for the 550cc and 700cc engine platforms used in Grizzly and Viking models.

Should I use sealant with this gasket?

This gasket is designed to provide a seal on its own when surfaces are cleaned thoroughly. However, a light smear of high-temp gasket sealant can be used if your engine surfaces have minor imperfections.
